Skoda Scala (2021 – 2023) – fuse and relay box diagram
Year of production: 2021, 2022, 2023
The Škoda Scala is a compact hatchback that was introduced in 2019, positioning itself between the Škoda Fabia and the larger Škoda Octavia in the brand’s lineup. It represents Škoda’s entry in the highly competitive compact car market, offering a combination of practicality, advanced technology, and good value for money. Built on the Volkswagen Group’s MQB A0 platform, the Scala shares its underpinnings with models like the Volkswagen Polo and SEAT Ibiza.
Key Features of the Škoda Scala:
1.Design:
•The Scala adopts Škoda’s modern design language with sharp, angular lines and a dynamic profile. Its design is clean yet sporty, featuring a prominent grille, sleek headlights, and a sculpted body.
•A notable design feature is the optional full-width rear glass tailgate with “ŠKODA” lettering prominently displayed, giving the car a premium feel.
•It also features LED headlights and taillights as standard, with full LED options available on higher trims.
2.Interior Space and Comfort:
•Despite being a compact hatchback, the Scala offers a spacious and practical interior, with ample legroom for both front and rear passengers.
•The boot capacity is one of the largest in its class, at 467 liters, expanding to 1,410 liters with the rear seats folded down, making it an excellent choice for those who need extra cargo space in a compact car.
•High-quality materials and thoughtful design elements make the cabin feel more premium than its price point might suggest.
3.Infotainment and Technology:
•The Scala is equipped with Škoda’s latest infotainment systems. The base models feature an 8-inch touchscreen, while higher trims come with a 9.2-inch touchscreen that supports Apple CarPlay, Android Auto, and MirrorLink.
•The Virtual Cockpit (digital instrument cluster) is available as an option, offering a customizable digital display instead of traditional dials.
•It also comes with a host of connectivity options, including wireless charging and up to four USB-C ports for charging devices.
4.Engine Options:
•The Scala is offered with a range of petrol and diesel engines, providing different power outputs to suit various driving needs:
•1.0 TSI: A 3-cylinder turbocharged petrol engine available with either 95 PS (manual only) or 110 PS.
•1.5 TSI: A 4-cylinder turbocharged petrol engine with 150 PS, offering more power while still being fuel-efficient thanks to cylinder deactivation technology.
•1.6 TDI: A 115 PS diesel engine for those prioritizing fuel economy, especially for long-distance driving.
•Transmission options include a 5-speed manual, 6-speed manual, and a 7-speed DSG automatic.
5.Safety and Driver Assistance:
•The Scala boasts a 5-star Euro NCAP safety rating, offering a range of advanced driver-assistance systems (ADAS), even in the base model:
•Lane Assist and Front Assist with autonomous emergency braking are standard.
•Adaptive Cruise Control, Blind Spot Monitoring, Rear Traffic Alert, and Park Assist are available on higher trims.
•Multiple airbags, including knee and side airbags, contribute to passenger safety.
6.Driving Experience:
•The Scala offers a balanced and comfortable ride, with handling tuned more for comfort than sportiness. It performs well in both urban environments and on highways, thanks to its refined suspension.
•The 1.0 TSI engine provides efficient and smooth performance for daily driving, while the 1.5 TSI offers more spirited driving dynamics for those who want extra power.
7.Practicality and “Simply Clever” Features:
•Like other Škoda models, the Scala includes Škoda’s signature “Simply Clever” features, such as:
•A hidden umbrella in the driver’s door.
•A removable boot light that doubles as a flashlight.
•A ticket holder on the windshield.
•Optional nets and hooks in the boot for better cargo organization.
Fuse box in passenger compartment
Fuse Box Location
The fuse box is located behind the storage compartment on the driver’s side of the dashboard.
Fuse Box Diagram
Assignment of the fuses in the Instrument panel (2021 – 2023)
| № | Consumer |
|---|---|
| 1 | Towing device |
| 2 | LED headlight – left-hand side |
| 3 | Music amplifier |
| 4 | Headlight washers |
| 5 | Sliding/tilting roof |
| 6 | Central locking, windscreen washer, rear wiper |
| 7 | Rear seat heating |
| 8 | Qimatronic, manual air conditioning, heater |
| 9 | LED headlight – right-hand side |
| 10 | Towing device |
| 11 | Electrically operated boot lid |
| 12 | Steering wheel heating |
| 13 | Light switch, diagnosis connection, rain sensor, control lever under the steering wheel, windscreen heater |
| 14 | Windscreen washer system |
| 15 | Instrument cluster, emergency call |
| 16 | Lights – right side |
| 17 | Electric window control – right-hand side |
| 18 | Windscreen wipers |
| 19 | The Infotainment system |
| 20 | Rear window heating |
| 21 | 2021: SCR (AdBlue) |
| 23 | Rear view camera |
| 24 | Phonebox, GSM areal, USB port, the Infotainment system display |
| 25 | Control lever under the steering wheel |
| 26 | Data bus |
| 27 | Suspension adjustment (adaptive chassis) |
| 28 | Alarm system sensor |
| 29 | Alarm siren |
| 30 | Ignition (switch box) |
| 31 | Air conditioning, heating |
| 32 | Passenger’s seat belt retractor |
| 33 | Electric window control – left-hand side |
| 34 | Driver’s seat belt retractor |
| 35 | Lights – left side |
| 36 | Horn |
| 37 | Front seat heating |
| 38 | Interior lighting, button lighting, headlight washers, backlighting, manual air conditioning, heating |
| 39 | Assist systems |
| 40 | Light switch, headlights, headlight levelling, diagnostic connector, reversing switch, control levers under the steering wheel |
| 41 | Interior mirror dimming, exterior mirror adjustment, air conditioning, CNG relay |
| 42 | Clutch pedal switch, starting |
| 43 | Rear window wiper |
| 44 | Airbag system, airbag control lamp |
| 45 | Windscreen wipers |
| 46 | Rear seat heating |
| 48 | Electric steering column lock, KESSY (keyless lock and start system) |
| 49 | SCR (AdBlue) / CNG |
| 50 | USB ports at the back, USB port by the rear-view mirror |
| 52 | Cigarette lighter /12V socket at front |
| 53 | Ignition key trigger lock, automatic transmission |
| 54 | 12V socket in the boot |
| 58 | Windscreen washer system |
| 59 | Wing mirrors heating, washer nozzles heating |
| 60 | Towing device |
| 61 | Towing device |
| 56 | Manual air conditioning, heating |
| 57 | Not used |
| 58 | Windscreen washer system |
| 59 | Exterior mirror heating, washer nozzle heating |
| 60 | Tow hitch |
| 61 | Tow hitch |
Fuse box in engine compartment
Fuse Box Location
Fuse Box Diagram
Assignment of the fuses in the engine compartment (2021 – 2023)
| № | Consumer |
|---|---|
| 1 | Engine control unit |
| 2 | Exhaust flap, water pump, radiator blinds, SCR (AdBlue), engine components |
| 3 | Lambda sensors, NOx control unit |
| 4 | Fuel pump |
| 5 | Radiator fan, fill pressure regulator, oil temperature and quantity sensor, engine components |
| 6 | Crankcase breather, glow plug system, engine components |
| 7 | Brake system (vacuum pump) |
| 8 | Fuel pump, engine components |
| 9 | Brake light switch |
| 10 | Data bus, BCM unit, vehicle battery status monitoring |
| 12 | Air conditioning |
| 14 | ESC, engine control system, engine components |
| 15 | Automatic gearbox |
| 17 | Engine control system |
| 18 | Starter |
| 20 | ESC |
| 21 | ESC |
| 25 | Radiator fan |
| 27 | Radiator fan |
| 28 | Electric auxiliary heater |
| 29 | Windscreen heating |
| 22 | Not used |
| 23 | Not used |
| 24 | Not used |
| 25 | Electric auxiliary heater, radiator fan |
| 27 | Electric auxiliary heater, radiator fan |
| 28 | Electric auxiliary heater |
| 29 | Heated windscreen |
WARNING: Terminal and harness assignments for individual connectors will vary depending on vehicle equipment level, model, and market.
